My client asked me for help. He needs to update the DEV environment every month
The current process (using export-import) takes a few days.
To reduce the time, an alternative approach was implemented
- Replicate constantly all production changes to a standby database. This is achieved using Data Guard
- For the refresh
- Stop synchronization
- Drop old DEV databases
- Create new DEV databases by cloning from the standby database
- Restart synchronization
The new procedure should considerably reduce the refresh time considerably to a few hours.
1 Pre-Requirements
- Oracle version and Patch Level on Primary and Secondary should be same.
- Db_unique_name on standby and primary database should be different in order to used in DG_CONFIG setting of the LOG_ARCHIVE_CONFIG parameter.
2 Preparation
Standby preparation
Check if standby is in sync with primary
****** To check archivelog apply lag SELECT al.thrd "Thread", almax "Last Seq Received", lhmax "Last Seq Applied" FROM (select thread# thrd, MAX(sequence#) almax FROM v$archived_log WHERE resetlogs_change#=(SELECT resetlogs_change# FROM v$database) GROUP BY thread#) al, (SELECT thread# thrd, MAX(sequence#) lhmax FROM v$log_history WHERE resetlogs_change#=(SELECT resetlogs_change# FROM v$database) GROUP BY thread#) lh WHERE al.thrd = lh.thrd;
Convert standby in snapshot standby
shutdown immediate startup mount alter database convert to snapshot standby; alter database open;
Create DB links between Standby and DEV
---- Standby alter pluggable database ALL open read only; CREATE USER c##r_clone identified by Oracle23 CONTAINER=ALL; GRANT CREATE SESSION, CREATE PLUGGABLE DATABASE, SYSOPER, RESOURCE, CREATE ANY TABLE, UNLIMITED TABLESPACE TO c##r_clone CONTAINER=ALL; GRANT DBA to c##r_clone; CREATE DATABASE LINK refresh_link CONNECT TO c##r_clone identified by Oracle23 using 'DUTSD'; ----- Dev Database CREATE DATABASE LINK refresh_link CONNECT TO c##r_clone identified by Oracle23 using 'DUTSST'; alter pluggable database ALL open read only; CREATE USER c##r_clone identified by Oracle23 CONTAINER=ALL; GRANT CREATE SESSION, CREATE PLUGGABLE DATABASE, SYSOPER, RESOURCE, CREATE ANY TABLE, UNLIMITED TABLESPACE TO c##r_clone CONTAINER=ALL; GRANT DBA to c##r_clone;
####### DROP OLD PDB - DUTSD Show pdbs; ALTER PLUGGABLE DATABASE <PDBNAME> CLOSE; DROP PLUGGABLE DATABASE <PDBNAME> INCLUDING DATAFILES;
3 Clone PDBs
The files of standby were created using OMF convention. For this reason the database files need to be converted from
+DATA01/DUTSD/<GUID>/DATAFILE/<file>.<id> to
+DATA01/DUTSST/DATAFILE/<file>.dbf’
CREATE PLUGGABLE DATABASE DUTSD FROM DUTSD@refresh_link storage unlimited tempfile reuse
file_name_convert=('+DATA01/DUTSD/CCA899613E3D0713E0531114C30A2022/DATAFILE/duts01.474.1147957609','+DATA01/DUTSST/DATAFILE/duts01.dbf',
'+DATA01/DUTSD/CCA899613E3D0713E0531114C30A2022/DATAFILE/duts02.269.1147957617','+DATA01/DUTSST/ /DATAFILE/duts02.dbf')
keystore identified by "Duts23" parallel 6;
4 Finalize the refresh
. oraenv sqlplus / as sysdba shutdown immediate startup mount
exec dbms_dnfs.restore_datafile_permissions('<CDBNAME>');
Convert the snapshot back to physical standby
show pdbs alter database convert to physical standby; shutdown immediate startup
See you soon in other articles.
